Ultra Bright Pink 14.2mm Single Digit 7 Segment LED Display
Ultra bright pink 14.2mm (0.56") single digit 7 segment LED display with common cathode configuration, designed for digital indicators and industrial applications.
Product Specifications
Package Dimension: 12.6 × 19 × 8mm
Character Height: 14.2mm (0.56 inch)
Polarity: Common Cathode
Color: Ultra Bright Pink
Face Color: Black
X & Y Coordinates: 0.29-0.31
Luminous Intensity: 100-120mcd/LED
Forward Voltage: 2.8-3.2V
Available Emitting Colors: Red, Blue, Yellow Green, Pure Green, White, Amber, Orange, and Yellow
Detailed Technical Parameters
Yellow Green (Code: J/JU)
Transform your displays with vibrant yellow green color, designed to enhance visual aesthetics and appeal for your specific design requirements.
| Parameter |
Symbol |
Condition |
Min |
Typ |
Max |
Unit |
| Forward Voltage |
Vf |
If=10mA |
1.8 |
|
2.4 |
V |
| Reverse Voltage |
Vr |
Ir=10uA |
5 |
|
|
V |
| Luminous Intensity |
Iv |
If=10mA |
30 |
|
40 |
mcd |
| Spectrum Width of Half Value |
△λ |
If=10mA |
|
20 |
|
nm |
| Wavelength |
Dλ |
If=10mA |
569 |
|
574 |
nm |
Amber/Yellow (Code: Y)
Warm amber/yellow hue providing a cozy glow that attracts attention and enhances display engagement.
| Parameter |
Symbol |
Condition |
Min |
Typ |
Max |
Unit |
| Forward Voltage |
Vf |
If=10mA |
1.8 |
|
2.5 |
V |
| Reverse Voltage |
Vr |
Ir=10uA |
5 |
|
|
V |
| Luminous Intensity |
Iv |
If=10mA |
60 |
|
80 |
mcd |
| Spectrum Width of Half Value |
△λ |
If=10mA |
|
20 |
|
nm |
| Wavelength |
Dλ |
If=10mA |
585 |
|
595 |
nm |
Orange (Code: F)
Vibrant orange color that injects energy and excitement into visual displays with flair and vigor.
| Parameter |
Symbol |
Condition |
Min |
Typ |
Max |
Unit |
| Forward Voltage |
Vf |
If=10mA |
1.8 |
|
2.4 |
V |
| Reverse Voltage |
Vr |
Ir=10uA |
5 |
|
|
V |
| Luminous Intensity |
Iv |
If=10mA |
60 |
|
80 |
mcd |
| Spectrum Width of Half Value |
△λ |
If=10mA |
|
20 |
|
nm |
| Wavelength |
Dλ |
If=10mA |
600 |
|
605 |
nm |
Super Bright Red (Code: R)
Captivating super bright red color ideal for commanding attention and making a powerful visual impact.
| Parameter |
Symbol |
Condition |
Min |
Typ |
Max |
Unit |
| Forward Voltage |
Vf |
If=10mA |
1.8 |
|
2.2 |
V |
| Reverse Voltage |
Vr |
Ir=10uA |
5 |
|
|
V |
| Luminous Intensity |
Iv |
If=10mA |
50 |
|
60 |
mcd |
| Spectrum Width of Half Value |
△λ |
If=10mA |
|
20 |
|
nm |
| Wavelength |
Dλ |
If=10mA |
630 |
|
635 |
nm |
Ultra Bright Red (Code: UR)
Intensely luminous red offering unparalleled visibility and commanding presence for maximum impact.
| Parameter |
Symbol |
Condition |
Min |
Typ |
Max |
Unit |
| Forward Voltage |
Vf |
If=10mA |
1.8 |
|
2.2 |
V |
| Reverse Voltage |
Vr |
Ir=10uA |
5 |
|
|
V |
| Luminous Intensity |
Iv |
If=10mA |
80 |
|
100 |
mcd |
| Spectrum Width of Half Value |
△λ |
If=10mA |
|
20 |
|
nm |
| Wavelength |
Dλ |
If=10mA |
625 |
|
635 |
nm |
Pure Green
Refreshing and crisp pure green color perfect for eco-friendly designs and conveying growth and sustainability.
| Parameter |
Symbol |
Condition |
Min |
Typ |
Max |
Unit |
| Forward Voltage |
Vf |
If=10mA |
2.6 |
|
3.2 |
V |
| Reverse Voltage |
Vr |
Ir=10uA |
5 |
|
|
V |
| Luminous Intensity |
Iv |
If=10mA |
120 |
|
180 |
mcd |
| Spectrum Width of Half Value |
△λ |
If=10mA |
|
20 |
|
nm |
| Wavelength |
Dλ |
If=10mA |
515 |
|
525 |
nm |
Ultra Bright Blue (Code: BH)
Vibrant cool blue color that infuses a refreshing and contemporary aesthetic into any display environment.
| Parameter |
Symbol |
Condition |
Min |
Typ |
Max |
Unit |
| Forward Voltage |
Vf |
If=10mA |
2.8 |
|
3.2 |
V |
| Reverse Voltage |
Vr |
Ir=10uA |
5 |
|
|
V |
| Luminous Intensity |
Iv |
If=10mA |
120 |
|
140 |
mcd |
| Spectrum Width of Half Value |
△λ |
If=10mA |
|
20 |
|
nm |
| Wavelength |
Dλ |
If=10mA |
460 |
|
465 |
nm |
Ultra Bright White (Code: WH)
Pristine white color providing unrivaled clarity and elegance for displays requiring sophisticated appeal.
| Parameter |
Symbol |
Condition |
Min |
Typ |
Max |
Unit |
| Forward Voltage |
Vf |
If=10mA |
2.8 |
|
3.2 |
V |
| Reverse Voltage |
Vr |
Ir=10uA |
5 |
|
|
V |
| Luminous Intensity |
Iv |
If=10mA |
120 |
|
140 |
mcd |
| LED Color Temperature |
K |
If=10mA |
5500 |
20 |
6800 |
K |
| Chromaticity Coordinates |
X/Y |
If=10mA |
0.29,0.32 |
|
0.30,0.33 |
nm |
Absolute Maximum Ratings (Ta=25ºC)
Performance specifications ensuring optimal reliability and operation under challenging conditions.
| Parameter |
Symbol |
Ratings |
Unit |
| Forward Current (per dice) |
Ipm |
20 |
mA |
| Reverse Voltage (per dice) |
Vr |
5 |
V |
| Power Dissipation (per dice) |
Pm |
80 |
mW |
| Operating Temperature Range |
Topr |
-40~+85 |
ºC |
| Storage Temperature Range |
Tstg |
-40~+85 |
ºC |
| Solder Temperature (≤3 seconds) |
Th |
260 |
ºC |
Manufacturer Information
Shenzhen Guangzhibao Technology Co., Ltd. (BRAND: LIGHT-BO) has been a leader in OEM and ODM solutions since 2006. With ISO 9001:2015 certification and over 15 years of experience, we are committed to innovation and superior quality. Our legacy is built on trust and expertise, consistently delivering cutting-edge solutions that push technological boundaries.
LIGHT-BO provides top-tier, cost-efficient custom solutions that enhance competitive advantages in global markets. We empower clients to succeed in dynamic market landscapes with the tools they need for success.
Product Applications
Our cutting-edge LED displays including Ultra Red 5×7 DOT Matrix Display, 7 Segment LED Display, Customized LED Display, and Numeric LED Display are engineered for seamless integration into various applications. These displays enhance functionality and aesthetic appeal for household appliances, temperature and humidity monitoring, refrigerator controllers, thermostats, and HVAC systems, delivering outstanding performance and quality.
Certifications & Quality Assurance
Office and Factory Overview
Company Exhibitions
Shipping & Transportation
Frequently Asked Questions
Q1: Are you a trading company or manufacturer?
A: We are original manufacturers with more than 20 years of experience in optoelectronic LED displays.
Q2: What are your main products?
A: Our main products include 7 Segment LED display, SMD LED Display, Dot matrix LED Display, Arrow LED display, Custom Design LED Display, LED light bar, Through hole LED, SMD LEDs, LED Backlights, and more.
Q3: What is your MOQ?
A: Our MOQ is 1000 pieces. We also accept sample orders and small quantities below our MOQ.
Q4: Can I get samples for testing before placing an order?
A: Yes. We can provide 5-10 free samples for testing, with freight costs borne by the customer.
Q5: How long is your delivery time?
A: Delivery time is approximately 10-20 days, depending on order quantity and raw material availability. For urgent orders with available materials, we can adjust production to 7-10 days.
Q6: What are your payment terms?
A: We accept bank transfer, T/T, Western Union, and PayPal for small amounts. Payment methods are negotiable.
Q7: Can you quote FOB prices?
A: Yes. We can quote prices based on incoterms EXW, FOB, CIF, and DDP.
Q8: How can I get your catalog and price list?
A: Please provide your email address or contact us directly through our website for our catalog and price list.
Q9: Can I negotiate prices?
A: Yes, we may consider discounts for bulk orders.
Q10: How much are the shipping charges?
A: Shipping charges depend on shipment size and method. We will provide charges upon request.
Q11: Can you do custom design products?
A: Yes, OEM & ODM services are available. We can customize sizes, LED colors, and functional icons according to your requirements.
Q12: If I send my design, will you keep it confidential?
A: Yes, we will not show or sell your design to others without your authorization.
Q13: What is the sample lead time for customized products?
A: Sample lead time is approximately 20-25 working days after receiving mold cost and approved mold drawings.
Q14: What are your shipping methods?
A: We typically ship via DHL, FedEx, UPS, EMS, by air, or by sea. You can choose the method that works best for you.
Q15: How do you ensure product quality?
A: As ISO 9001 certified manufacturers with over 20 years of experience, we conduct twice 100% testing on all products before shipment.
